- Screw Nominal (M)
- 6
- Material
- Stainless Steel
- EN 1.4301 Equiv.
- Surface Treatment
- Thread Type
- Metric Coarse
- Metric Coarse
- Surface Treatment (Details)
- Shape Detail
- Width A(mm)[144–200/1mm jednotek]
- Width B(mm)
- 16
- Hole Distance P(mm)[12–138/1mm jednotek]
- Type
- Type
- CAD
- 2D
- 3D
- Odhadované dodací dny
- Vše
- V rámci 7 pracovních dnů
Rectangular Washers&Nuts with Two Clearance Holes (FK2TS16-A150-P132)
- Jednotková cena (bez DPH)
- 10.51 €
- Celkem (bez DPH)
- 10.51 €Cena včetně DPH: 12.51 €
- Datum odeslání
- 7 pracovních dnůReferenční datum odeslání: 30.06.2025
| Množství | 1 - 49 | 50 - 100 | 101+ |
|---|---|---|---|
| Jednotková cena (bez DPH) (Jednotková cena včetně DPH) | 10.51 € (12.51 €) | 8.61 € (10.25 €) | 8.61 € (10.25 €) |
| Shipping days | 7 days | 7 days | Quote |
- * Informace o dnech dodání, přepravních nákladech a cenách
Obrysový výkres a tabulka specifikací
Dimensional Drawing
Nuts
Washers
| Type | Material | Surface Treatment | |
| Nuts | Washers | ||
| FK2T | FK2W | EN 1.1191 Equiv.(cold drawn) | — |
| FK2TB | FK2WB | EN 1.1191 Equiv.(cold drawn) | Black Oxide |
| FK2TS | FK2WS | EN 1.4301 Equiv. | — |
Specification Table
| Part Number | — | A | — | P |
| FK2TS10 | — | A25 | — | P15 |
| Part Number | — | A | — | P | — | D |
| FK2T16 FK2WS25 | — — | A40 A50 | — — | P25 P20 | — | D7 |
Dimension Fixed
| Part Number | A | P | M | T | |
| Type | B | ||||
| Nuts FK2TS | 10 | 25 | 15 | 2 | 3 |
| 30 | 20 | 3 | 3 | ||
| 35 | 25 | 3 | 3 | ||
| 50 | 40 | 3 | 3 | ||
| 16 | 30 | 15 | 6 | 6 | |
| 40 | 20 | 6 | 6 | ||
| 50 | 30 | 6 | 6 | ||
| 60 | 40 | 6 | 6 | ||
| 120 | 100 | 6 | 6 | ||
Dimension Configurable
| Part Number | 1 mm Increments | M (Coarse) | T | ||
| Type | B | A | P | ||
| Nuts FK2T FK2TB FK2TS (B = 6, B = 10 are for FK2TS only) | (6) | 30 to 200 | 2M ≤ P ≤ A−2M | 3 | 2 |
| (10) | 3 | 3 | |||
| 16 | 6 | 6 | |||
| 22 | 8 | 6 | |||
| 25 | 10 | 9 | |||
| 38 | 12 | 10 | |||
| Part Number | 1 mm Increments | D Selection | T | |||||||
| Type | B | A | P | |||||||
| Washers FK2W FK2WB FK2WS (B = 6, B = 10 are for FK2WS only) | (6) | 30 to 200 | 2D ≤ P ≤ A - 2D | 4 | 2 | |||||
| (10) | 4 | 6 | 3 | |||||||
| 16 | 7 | 9 | 6 | |||||||
| 22 | 7 | 9 | 6 | |||||||
| 25 | 7 | 9 | 11 | 14 | 6 | |||||
| 38 | 7 | 9 | 11 | 14 | 6 | |||||
■ Tolerance
| mm | A | B | D | P |
| 4 to 6 | - | +1.0 -0.3 | ±0.1 | - |
| 7 to 10 | ±0.2 | +2.0 -0.36 | ±0.2 | ±0.2 |
| 11 to 18 | ±0.2 | +0.2 -0.43 | ±0.2 | ±0.2 |
| 19 to 30 | ±0.2 | +0.2 -0.52 | ±0.2 | ±0.2 |
| 31 to 50 | ±0.3 | +0.3 -0.62 | - | ±0.3 |
| 51 to 80 | ±0.3 | +0.3 -0.74 | - | ±0.3 |
| 81 to 120 | ±0.3 | +0.3 -0.87 | - | ±0.3 |
| 121 to 194 | ±0.5 | - | - | - |
Podrobné údaje
Základní informace
This product can be specified in 1 mm increments in overall length. 2-circle type. Available in quantities of 1 piece, this product is only suitable for use in small quantities.
