Scale Plates (MEPCT-300)

■Horizontal Scale Type

Width	Type			Material	Mounting Specification	Alterations
	Zero Point Position					Hole Machining	Length Cut
	Left End	Right End	Center (Divided)			HC	LC
8mm	MEPLH	MEPRH	MEPCH	EN AW-1050 Equiv. (Clear Anodize)	With adhesive tape	-	○
8mm	MEPLSH	MEPRSH	MEPCSH	EN 1.4301 Equiv.	With mounting hole	-	○
12mm	MEPL	MEPR	MEPC MES (T=0.15)	EN AW-1050 Equiv. (Clear Anodize)	With adhesive tape	○	○
12mm	MEPLS	MEPRS	MEPCS	EN 1.4301 Equiv.	With mounting hole	○	○
12mm	MEPLP (T=0.2)	MEPRP (T=0.2)	MEPCP (T=0.2)	PET Plastic	With adhesive tape	-	-

■Vertical Scale Type

Width	Type		Material	Mounting Specification	Alterations
	Zero Point Position				Hole Machining	Length Cut
	Bottom	Center (Divided)			HC	LC
15mm	MEPCTT	MEPCT	EN AW-1050 Equiv. (Clear Anodize)	With adhesive tape	○	○
	-	MEPCTP (T=0.2)	PET Plastic		-	-

For types with no T dimension listed, T = 0.5.
For adhesive tapes, NITTO500 is used. (Plate thickness [T] does not include tape thickness)

■Scale Plates Width 12mm Zero at Left/Right

Zero Point Position	Part Number		Unit Price	Volume Discount Rate
	Type	L	1 ~ 19 pc(s).	20~29	30~49	50~100
Left End	MEPL	100
		200
		300
		600
	MEPLS	100
		200
	MEPLP	200
Right End	MEPR	100
		200
		300
		600
	MEPRS	100
		200
	MEPRP	200

  L600 is a set of two pieces, one with a scale of 0 to 300 and one with a scale of 301 to 600.  For orders larger than indicated quantity, please check with WOS.

■Scale Plates Width 15mm Vertical Type

Zero Point Position	Part Number		Unit Price	Volume Discount Rate
	Type	L	1 ~ 19 pc(s).	20~29	30~49	50~100
Bottom	MEPCTT	100
		200
		300
Center	MEPCT	300
	MEPCTP

  For orders larger than indicated quantity, please check with WOS.

■Scale Plates Width 8mm Type

Zero Point Position	Part Number		Unit Price	Volume Discount Rate
	Type	L	1 ~ 19 pc(s).	20~29	30~49	50~100
Left End	MEPLH	100 200
	MEPLSH
Right End	MEPRH
	MEPRSH
Center	MEPCH	300
	MEPCSH

  For orders larger than indicated quantity, please check with WOS.

 ■ Scale Plates Width 12mm Center Divided Type

Zero Point Position	Part Number		Unit Price	Volume Discount Rate
	Type	L	1 ~ 19 pc(s).	20~29	30~49	50~100
Center	MEPC	300
	MEPCS
	MEPCP
	MES

  For orders larger than indicated quantity, please check with WOS.
