Specification Table

Model Number		Blade Diameter D 0.1 mm Unit Specification	Straight Blade Length ℓ 0.1 mm Unit Specification	Single Corner θ °−min 1' Unit Specification	Inverted Taper Blade Length ℓ1 0.1 mm Unit Specification			Neck Length ℓ2 0.5mm Unit Specification	Overall Length L
	Shank diameter d				Inverted Taper Blade Length ℓ1 0.1 mm Unit Specification
	Shank diameter d				θ5°0′ to 10°	θ10°1′ to 15°	θ15°1′ to 20°
SSBTEM	3	2.0 to 3.0	1.0 to 2.0	5°0' to 20°0'	2.0 to 2.5	1.0	0.7	1.0 to 2.0	40
	4	3.0 to 4.0	1.0 to 3.0		2.0 to 4.0	2.0 to 2.5	1.0 to 1.5	1.0 to 4.0	50
	6	4.0 to 6.0	1.0 to 6.0		3.0 to 5.0	3.0 to 4.0	2.0 to 4.0	2.0 to 6.0	60
	8	6.0 to 8.0	1.0 to 8.0		4.0 to 9.0	4.0 to 6.0	2.0 to 5.0	2.0 to 8.0	60
	10	8.0 to 10.0	1.0 to 10.0		5.0 to 13.0	5.0 to 8.0	2.0 to 8.0	2.0 to 10.0	80
	12	10.0 to 12.0	1.0 to 12.0		6.0 to 17.0	6.0 to 11.0	2.0 to 10.0	2.0 to 10.0	80
	16	12.0 to 16.0	1.0 to 16.0		8.0 to 18.0	8.0 to 12.0	2.0 to 11.0	2.0 to 10.0	100
