  • PCR Series

    Číslo dílu:

    Nebyly nalezeny žádné nevyřízené. 17 návrhy.
    Množství:

    Seznam čísel dílů

    Počet položek

    Applicable pin/contact

    Number Of Cores

    Application

    Wire connection method

    Connection direction

    Features

    Conforming cable size

    Quantity of units ordered

    (Piece)

    RoHS?Minimální objednací množství
    Female
    20
    [Cable Connection] Cable to Circuit Board
    Pressure Welding
    Straight
    Note EMI-compatible
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    20
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    Note EMI-compatible
    AWG#28 MAX
    -
    -
    1 kusů
    Male
    20
    For Circuit Boards
    -
    Right Angle
    Dip type / EMI measures
    NA
    10
    10
    1 kusů
    Male
    20
    For Circuit Boards
    -
    Straight
    Dip type / EMI measures
    NA
    10
    10
    1 kusů
    Female
    36
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    Note EMI-compatible
    AWG#28 MAX
    -
    -
    1 kusů
    Female
    50
    [Cable Connection] Cable to Circuit Board
    Pressure Welding
    Straight
    Note EMI-compatible
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    50
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    Note EMI-compatible
    AWG#28 MAX
    -
    -
    1 kusů
    Male
    50
    For Circuit Boards
    -
    Right Angle
    Dip type / EMI measures
    NA
    10
    10
    1 kusů
    Male
    50
    For Circuit Boards
    -
    Straight
    Dip type / EMI measures
    NA
    10
    -
    1 kusů
    Male
    50
    Panel Mount
    Pressure Welding
    Straight
    EMI Measure
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    68
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    Note EMI-compatible
    AWG#28 MAX
    -
    -
    1 kusů
    Male
    68
    Panel Mount
    Pressure Welding
    Straight
    EMI Measure
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    96
    [Cable Connection] Cable to Circuit Board
    Pressure Welding
    Straight
    Note EMI-compatible
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    96
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    Note EMI-compatible
    AWG#28 MAX
    -
    10
    1 kusů
    Male
    96
    Panel Mount
    Pressure Welding
    Straight
    EMI Measure
    AWG#28 (7/0.127) AWG#30 (1/0.254) discrete wire
    -
    10
    1 kusů
    Female
    20
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    EMI Measure
    AWG#20 MAX
    -
    10
    1 kusů
    Female
    50
    [Cable Connection] Cable to Circuit Board
    Solder
    Straight
    EMI Measure
    AWG#20 MAX
    -
    10
    1 kusů
    Jednotková cena (bez DPH)(Jednotková cena včetně DPH)
    Standardní datum odeslání
    10.88 €
    ( 12.95 € )
    6 pracovních dnů
    8.56 €
    ( 10.19 € )
    6 pracovních dnů
    9.95 €
    ( 11.84 € )
    6 pracovních dnů
    7.41 €
    ( 8.82 € )
    6 pracovních dnů
    9.70 €
    ( 11.54 € )
    6 pracovních dnů
    14.46 €
    ( 17.21 € )
    6 pracovních dnů
    9.75 €
    ( 11.60 € )
    6 pracovních dnů
    14.18 €
    ( 16.87 € )
    6 pracovních dnů
    11.94 €
    ( 14.21 € )
    6 pracovních dnů
    29.48 €
    ( 35.08 € )
    6 pracovních dnů
    14.30 €
    ( 17.02 € )
    6 pracovních dnů
    39.18 €
    ( 46.62 € )
    6 pracovních dnů
    19.29 €
    ( 22.96 € )
    6 pracovních dnů
    39.24 €11.77 €
    ( 14.01 € )
    Skladová položka: 1 pracovní denK dispozici odeslání ve stejný den
    38.47 €
    ( 45.78 € )
    6 pracovních dnů
    4.64 €
    ( 5.52 € )
    Skladová položka: 1 pracovní denK dispozici odeslání ve stejný den
    10.17 €
    ( 12.10 € )
    6 pracovních dnů

    Podrobné údaje

    Základní informace

    Bellows, high-density contact type and accessories are, as with the PCS series, applicable to various uses.

    [Features]
    · A wide range of cores of 20 to 96 are available from the board to the cable.
    · For EMI measures other than FCC.
    · A wide range of cores of 20 to 128 are available from board to board.
    · Products enabling live wire connection (three steps) are available.
    · Parallel mating is feasible through a housing guide mechanism and the structure prevents shorting between adjacent contacts.
    · Ideal for connection to horizontal, parallel, and vertical backs.
