Discrete Wire Connector for Connection, DF3 Series (2 mm Pitch)【1-100 Pieces Per Package】

Volume Discount

Connector for board-to-cable, cable-to-cable, and board-to-board connections with 2-mm pitch 1 terminal row. Can use for a wide range of equipment.
In-stock items are custom products, therefore returns and cancellations are not possible. Thank you.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Products homepage

Data to be displayed: 30; 45; 60

Part Number
DF3-2EP-2C
DF3-2P-2DS(01)
DF3-2P-2DSA(01)
DF3-2S-2C
DF3-2S-2DSA(25)
DF3-3EP-2C
DF3-3P-2DS(01)
DF3-3P-2DSA(01)
DF3-3S-2C
DF3-4EP-2C
DF3-4P-2DS(01)
DF3-4P-2DSA(01)
DF3-4S-2C
DF3-5EP-2C
DF3-5P-2DSA(01)
DF3-5S-2C
DF3-6EP-2C
DF3-6P-2DS(01)
DF3-6P-2DSA(01)
DF3-6S-2C
DF3-7P-2DSA(01)
DF3-7S-2C
DF3-8EP-2C
DF3-8P-2DSA(01)
DF3-8S-2C
DF3-9EP-2C
DF3-9S-2C
DF3-10S-2C
DF3-12S-2C
DF3-13S-2C
DF3-14S-2C
DF3-15S-2C
DF3-22SC
DF3-22SCC
DF3-22SCF
DF3-2428SC
DF3-2428SCC
DF3-EP2428PC
DF3-EP2428PCA
DF3A-2P-2DS
DF3A-2P-2DSA
DF3A-3P-2DS
DF3A-3P-2DSA
DF3A-4P-2DS
DF3A-4P-2DSA
DF3A-5P-2DS
DF3A-5P-2DSA
DF3A-6P-2DS
DF3A-7P-2DS
DF3A-7P-2DSA
DF3A-8P-2DS
DF3A-8P-2DSA
DF3A-9P-2DS
DF3A-10P-2DS
DF3A-10P-2DSA
DF3A-11P-2DSA
DF3A-14P-2DSA
DF3AA-2EP-2C
DF3AA-3EP-2C
DF3AA-4EP-2C

Standard Unit Price	Number of pc(s). included in pkg.	Minimum order quantity	Volume Discount	Standard Shipping Days ?	RoHS	Applicable pin/contact	Number Of Cores	Connector Type	Allowable Voltage (V)	Wiring Method	Connection direction	Plating of part touching terminal	Product Category	Conforming wire size (AWG)	Contact Pitch (mm)	Operating Temperature Range (°C)	Terminal pitch (mm)
8.96 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Male	2	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.19 €		10	Available	5 Days	10	Male	2	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Gold	Pin Header	NA	2	-55 – 105	2
0.14 €		10	Available	5 Days	10	Male	2	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
3.53 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	2	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.37 €		5	Available	5 Days	-	Female	2	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Receptacle	NA	2	-55 – 105	2
0.11 €		10	Available	6 Days	-	Male	3	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.25 €		5	Available	6 Days	-	Male	3	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Gold	Pin Header	NA	2	-55 – 105	2
0.22 €		5	Available	6 Days	-	Male	3	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
3.87 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	3	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.12 €		10	Available	6 Days	-	Male	4	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.31 €		5		6 Days	-	Male	4	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Gold	Pin Header	NA	2	-55 – 105	2
0.26 €		5	Available	6 Days	-	Male	4	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
4.14 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	4	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.12 €		10		6 Days	-	Male	5	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.33 €		5	Available	5 Days	-	Male	5	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
5.56 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Female	5	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.14 €		10	Available	6 Days	-	Male	6	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.44 €		5		6 Days	-	Male	6	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Gold	Pin Header	NA	2	-55 – 105	2
0.34 €		5	Available	5 Days	10	Male	6	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
5.90 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	6	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.40 €		5	Available	6 Days	-	Male	7	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
6.55 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	7	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.17 €		10	Available	6 Days	-	Male	8	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
0.45 €		5	Available	6 Days	-	Male	8	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Gold	Pin Header	NA	2	-55 – 105	2
7.02 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	8	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
0.19 €		10	Available	5 Days	-	Male	9	[Cable Connection] Cable Connection	-	-	Straight	No terminal	Relay plug	NA	2	-55 – 105	2
7.59 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Female	9	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
8.01 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	10	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
8.75 €	100 Pieces Per Package	1 pack		6 Days	-	Female	12	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
9.07 €	100 Pieces Per Package	1 pack		6 Days	-	Female	13	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
9.45 €	100 Pieces Per Package	1 pack		6 Days	-	Female	14	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
9.80 €	100 Pieces Per Package	1 pack		6 Days	-	Female	15	[Cable Connection] Cable Connection	AC250	Crimp	Straight	No terminal	Socket	NA	2	-55 – 105	2
4.58 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	-	-	AC250	Crimp	-	Tin	Loose terminal	22	NA	-55 – 105	NA
8.53 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	-	-	AC250	Crimp	-	Gold	Loose terminal	22	NA	-55 – 105	NA
0.09 €		100		13 Days	-	Female	-	-	AC250	Crimp	-	-	-	22	-	-30~+85	-
2.80 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Female	-	-	AC250	Crimp	-	Tin	Loose terminal	28 to 24	NA	-55 – 105	NA
7.08 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Female	-	-	AC250	Crimp	-	Gold	Loose terminal	28 to 24	NA	-55 – 105	NA
3.63 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Male	-	-	AC250	Crimp	-	Tin	Loose terminal	28 to 24	NA	-55 – 105	NA
14.94 €	100 Pieces Per Package	1 pack	Available	5 Days	-	Male	-	-	AC250	Crimp	-	Gold	Loose terminal	28 to 24	NA	-55 – 105	NA
7.16 €	100 Pieces Per Package	1 pack		6 Days	-	Male	2	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
5.52 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Male	2	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
7.72 €	100 Pieces Per Package	1 pack		6 Days	-	Male	3	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
7.51 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Male	3	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
9.68 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Male	4	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
8.00 €	100 Pieces Per Package	1 pack		6 Days	-	Male	4	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
11.73 €	100 Pieces Per Package	1 pack		6 Days	-	Male	5	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
10.24 €	100 Pieces Per Package	1 pack		6 Days	-	Male	5	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
12.51 €	100 Pieces Per Package	1 pack		6 Days	-	Male	6	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
13.45 €	100 Pieces Per Package	1 pack		6 Days	-	Male	7	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
13.48 €	100 Pieces Per Package	1 pack		6 Days	-	Male	7	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
17.72 €	100 Pieces Per Package	1 pack		6 Days	-	Male	8	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
14.92 €	100 Pieces Per Package	1 pack	Available	6 Days	-	Male	8	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
19.19 €	100 Pieces Per Package	1 pack		6 Days	-	Male	9	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
19.95 €	100 Pieces Per Package	1 pack		6 Days	-	Male	10	For PCB	-	[Other] Circuit Board Mounting (DIP)	Angle	Tin	Pin Header	NA	2	-55 – 105	2
16.95 €	100 Pieces Per Package	1 pack		6 Days	-	Male	10	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
17.62 €	100 Pieces Per Package	1 pack		6 Days	-	Male	11	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
19.73 €	100 Pieces Per Package	1 pack		6 Days	-	Male	14	For PCB	-	[Other] Circuit Board Mounting (DIP)	Straight	Tin	Pin Header	NA	2	-55 – 105	2
0.11 €		10	Available	5 Days	10	Male	2	Panel Mount	-	-	Straight	No terminal	Relay plug with panel lock	NA	2	-55 – 105	2
0.12 €		10	Available	5 Days	10	Male	3	Panel Mount	-	-	Straight	No terminal	Relay plug with panel lock	NA	2	-55 – 105	2
0.12 €		10		6 Days	-	Male	4	Panel Mount	-	-	Straight	No terminal	Relay plug with panel lock	NA	2	-55 – 105	2

Basic information

Connector Shape	Rectangular	Connector series initials	D/E/F	D/E/F	DF
Rated Current(A)	3	Representative Standard	UL / CSA
