High-Density Multipolar Round Connector HR22 Series【1 až 100 kusů】

Číslo dílu:

Nebyly nalezeny žádné nevyřízené. 11 návrhy.
Množství:

Seznam čísel dílů

Počet položek

Applicable pin/contact

Number Of Cores

Connector Type

Wiring Method

Connection direction

Protection function (environmentally resistant)

Shell Size

Plating of part touching terminal

Product Category

Conforming cable outer diameter

(mm)

Mating partner 1

Mating partner 2

Mating partner 3

Mating partner 4

Mating partner 5

RoHS?Minimální objednací množství
Male
20
Cable Connection
Solder
Straight
N/A
12
Silver
Jack
φ8.5
HR22-12TPD-20SC(73)
HR22-12TPD-20S(73)
HR22-12WTPA-20SC(73)
HR22-12WTPA-20S(73)
-
10
1 kusů
Female
20
Cable Connection
Solder
Straight
N/A
12
Silver
Jack
φ8.5
HR22-12TPD-20PC(73)
HR22-12TPD-20P(73)
HR22-12WTPA-20P(73)
HR22-12WTLP-20PC
HR22-12WTLP-20P(73)
10
1 kusů
Male
20
Cable Connection
Solder
Straight
N/A
12
Silver
Plug
φ8.5
HR22-12WTRA-20SC(73)
HR22-12WTRA-20S(73)
HR22-12TJD-20S(73)
HR22-12WTJA-20SC(73)
-
-
1 kusů
Male
20
Cable Connection
Crimp
Straight
N/A
12
NA
Plug
φ8.5
HR22-12WTRA-20SC(73)
HR22-12WTRA-20S(73)
HR22-12TJD-20S(73)
HR22-12WTJA-20SC(73)
-
10
1 kusů
Female
20
Cable Connection
Crimp
Straight
N/A
12
NA
Plug
φ8.5
HR22-12WTRA-20PC(73)
HR22-12WTRA-20P(73)
HR22-12WTJA-20PC(73)
HR22-12TJD-20P(73)
-
-
1 kusů
Male
20
Cable Connection
Crimp
Straight
[Available] Waterproof Type
12
NA
Jack
φ10
HR22-12TPD-20SC(73)
HR22-12TPD-20S(73)
HR22-12WTPA-20SC(73)
HR22-12WTPA-20S(73)
-
10
1 kusů
Female
20
Cable Connection
Crimp
Straight
[Available] Waterproof Type
12
NA
Plug
φ10
HR22-12WTRA-20PC(73)
HR22-12WTRA-20P(73)
HR22-12WTJA-20PC(73)
HR22-12TJD-20P(73)
-
10
1 kusů
Male
20
Panel Mount
Solder
Straight
[Available] Waterproof Type
12
Silver
Receptacle
-
HR22-12TPD-20SC(73)
HR22-12TPD-20S(73)
HR22-12WTPA-20SC(73)
HR22-12WTPA-20S(73)
-
-
1 kusů
Male
20
Panel Mount
Crimp
Straight
[Available] Waterproof Type
12
NA
Receptacle
-
HR22-12TPD-20SC(73)
HR22-12TPD-20S(73)
HR22-12WTPA-20SC(73)
HR22-12WTPA-20S(73)
-
10
1 kusů
Male
-
-
Crimp
-
N/A
-
Silver
Loose terminal
-
-
-
-
-
-
-
9 kusů
Female
-
-
Crimp
-
N/A
-
Silver
Loose terminal
-
-
-
-
-
-
-
1 balení

100 kusů

Jednotková cena (bez DPH)(Jednotková cena včetně DPH)
Standardní datum odeslání
22.91 €
(
27.26 €
)
6 pracovních dnů
51.37 €
(
61.13 €
)
6 pracovních dnů
22.88 €
(
27.23 €
)
6 pracovních dnů
20.32 €
(
24.18 €
)
6 pracovních dnů
20.31 €
(
24.17 €
)
6 pracovních dnů
31.57 €
(
37.57 €
)
6 pracovních dnů
38.10 €
(
45.34 €
)
6 pracovních dnů
16.59 €
(
19.74 €
)
6 pracovních dnů
14.15 €
(
16.84 €
)
6 pracovních dnů
0.53 €
(
0.63 €
)
6 pracovních dnů
12.89 €
(
15.34 €
)
6 pracovních dnů

Podrobné údaje

Základní informace

This is a multi-pin round connector that uses a vibration-resistant screw-coupling structure. (The interior of the coupling is equipped with a spring that prevents loosening of the screws.) Waterproof type and non-waterproof type.

[Features]
・There are two types, waterproof and non-waterproof, and each is compatible. The internal structure of the waterproof type is such that it can operate after being submerged at a depth of 1.8 m for 48 hours in a fitted condition, with no ingress of water.
・The structure prevents lock loosening. The lock structure has a screw coupling system in which the interior of the coupling is equipped with a spring that prevents loosening.
・There are 2 wiring work systems: Crimped types and soldered types. Users can choose depending on the application.
・Receptacle installation is easy. From the panel surface, the nut fastening system makes receptacle installation fast and easy.
・There are types that also take into consideration lack of flexibility. By covering the shell with a code bushing, the bending radius is enlarged, and this prevents disconnections when the cable is flexed.
・It has a high-density layout. Although there are 20 poles, the maximum outer diameter of the plug is Ø 21, which is very high density.
