AG Long Power Drill AGPLSD

Volume Discount

Well suited for deep hole machining on materials ranging from green timber to die steel. Can machine deep holes up to L/D20 without stopping.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Data to be displayed: 30; 45; 60

Part Number
AGPLSD1.0X56
AGPLSD1.0X100
AGPLSD1.1X60
AGPLSD1.1X100
AGPLSD1.2X65
AGPLSD1.2X105
AGPLSD1.3X65
AGPLSD1.3X105
AGPLSD1.4X70
AGPLSD1.4X110
AGPLSD1.5X70
AGPLSD1.5X110
AGPLSD1.6X76
AGPLSD1.6X115
AGPLSD1.7X76
AGPLSD1.7X115
AGPLSD1.8X120
AGPLSD1.9X80
AGPLSD1.9X120
AGPLSD2.0X85
AGPLSD2.0X125
AGPLSD2.1X85
AGPLSD2.1X125
AGPLSD2.2X90
AGPLSD2.2X135
AGPLSD2.3X90
AGPLSD2.3X135
AGPLSD2.4X95
AGPLSD2.4X140
AGPLSD2.5X95
AGPLSD2.5X140
AGPLSD2.6X95
AGPLSD2.6X140
AGPLSD2.7X100
AGPLSD2.7X150
AGPLSD2.8X100
AGPLSD2.8X150
AGPLSD2.9X100
AGPLSD2.9X150
AGPLSD3.0X100
AGPLSD3.0X150
AGPLSD3.0X190
AGPLSD3.1X106
AGPLSD3.1X155
AGPLSD3.2X106
AGPLSD3.2X155
AGPLSD3.3X106
AGPLSD3.3X155
AGPLSD3.4X112
AGPLSD3.4X165
AGPLSD3.5X112
AGPLSD3.5X165
AGPLSD3.5X210
AGPLSD3.6X112
AGPLSD3.6X165
AGPLSD3.7X112
AGPLSD3.7X165
AGPLSD3.8X119
AGPLSD3.8X175
AGPLSD3.9X119

Standard Unit Price	Minimum order quantity	Standard Shipping Days ?	Diameter Dc (mm)	Groove Length L (mm)	Overall Length L (mm)	Series (Series)
21.65 €	1	6 Days	1	33	56	1
25.88 €	1	6 Days	1	60	100	2
36.12 €	1	10 Days	1.1	37	60	1
30.55 €	1	8 Days	1.1	60	100	2
25.88 €	1	8 Days	1.2	41	65	1
30.55 €	1	6 Days	1.2	65	105	2
25.88 €	1	8 Days	1.3	41	65	1
30.55 €	1	8 Days	1.3	65	105	2
36.12 €	1	10 Days	1.4	45	70	1
32.10 €	1	6 Days	1.4	70	110	2
33.29 €	1	6 Days	1.5	45	70	1
30.98 €	1	10 Days	1.5	70	110	2
30.64 €	1	10 Days	1.6	50	76	1
34.67 €	1	8 Days	1.6	75	115	2
39.53 €	1	10 Days	1.7	50	76	1
45.19 €	1	10 Days	1.7	75	115	2
36.31 €	1	10 Days	1.8	80	120	2
39.53 €	1	10 Days	1.9	53	80	1
34.67 €	1	8 Days	1.9	80	120	2
27.47 €	1	10 Days	2	56	85	1
33.07 €	1	6 Days	2	85	125	2
32.01 €	1	8 Days	2.1	56	85	1
39.85 €	1	8 Days	2.1	85	125	2
32.01 €	1	8 Days	2.2	59	90	1
42.13 €	1	6 Days	2.2	90	135	2
42.76 €	1	10 Days	2.3	59	90	1
42.13 €	1	6 Days	2.3	90	135	2
33.88 €	1	10 Days	2.4	62	95	1
42.13 €	1	6 Days	2.4	95	140	2
32.10 €	1	10 Days	2.5	62	95	1
48.43 €	1	10 Days	2.5	95	140	2
33.88 €	1	6 Days	2.6	62	95	1
39.85 €	1	8 Days	2.6	95	140	2
36.68 €	1	8 Days	2.7	66	100	1
46.84 €	1	6 Days	2.7	100	150	2
38.56 €	1	6 Days	2.8	66	100	1
46.84 €	1	6 Days	2.8	100	150	2
36.68 €	1	8 Days	2.9	66	100	1
46.86 €	1	6 Days	2.9	100	150	2
34.98 €	1	8 Days	3	66	100	1
45.08 €	1	10 Days	3	100	150	2
63.07 €	1	6 Days	3	130	190	3
52.46 €	1	10 Days	3.1	69	106	1
53.84 €	1	6 Days	3.1	105	155	2
52.46 €	1	6 Days	3.2	69	106	1
53.86 €	1	6 Days	3.2	105	155	2
43.60 €	1	10 Days	3.3	69	106	1
53.87 €	1	10 Days	3.3	105	155	2
52.46 €	1	10 Days	3.4	73	112	1
53.89 €	1	10 Days	3.4	115	165	2
41.55 €	1	6 Days	3.5	73	112	1
48.19 €	1	8 Days	3.5	115	165	2
70.14 €	1	6 Days	3.5	145	210	3
44.74 €	1	6 Days	3.6	73	112	1
53.91 €	1	6 Days	3.6	115	165	2
41.49 €	1	7 Days	3.7	73	112	1
53.94 €	1	6 Days	3.7	115	165	2
47.01 €	1	8 Days	3.8	78	119	1
58.11 €	1	8 Days	3.8	120	175	2
47.03 €	1	8 Days	3.9	78	119	1

Basic information

work material	General Steel / Quenched and tempered steel / Cast Iron	Tool Material Type	Cobalt HSS	Coating Y/N	Available
Coating Type	Other	Coating Details	AG Coating (AlCr-Based)	tip angle(Degree)	118

Configure

138Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Diameter Dc(mm)
1

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

2

2.1

2.2

2.3

2.4

2.5

2.6

2.7

2.8

2.9

3

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

4

4.1

4.2

4.3

4.4

4.5

4.6

4.7

4.8

4.9

5

5.1

5.2

5.3

5.4

5.5

5.6

5.7

5.8

5.9

6

6.5

6.8

7

7.5

8

8.5

9

9.5

10

10.5

11

11.5

12

12.5

13
Clear
Groove Length L(mm)
33

37

41

45

50

53

56

59

60

62

65

66

69

70

73

75

78

80

82

85

87

90

91

95

97

100

102

105

109

115

120

121

125

128

130

134

135

140

145

150

155

160

165

175

180

185

190

200

210

220

225

235
Clear
Overall Length L(mm)
56

60

65

70

76

80

85

90

95

100

105

106

110

112

115

119

120

125

126

132

135

139

140

148

150

155

156

165

175

184

185

190

195

205

210

215

220

225

235

240

250

260

265

275

290

305

320

330

340
Clear
Type
- AGPLSD
Clear
