Deep groove ball bearings / single row / MINEBEA

Volume Discount

The most typical type of radial ball bearings. Besides radial load, it can receive axial load in both directions.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Products homepage

Data to be displayed: 30; 45; 60

Part Number
DDL-1040
DDL-1280
DDL-1910
DDL-310
DDL-415
DDL-520
DDL-520W52
DDL-625
DDL-630
DDL-730
DDL-740
DDL-940
DDR-1340
DDR-515
DDR-620
DDR-830
L-1050
L-1680
R-830

Standard Unit Price	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Materials of Inner and Outer Ring	Shield material and shape	I.D. D (φ)	Outer Diameter D (φ)	Width B (mm)	Rolling Element Material	Basic Load Rating Dynamic Rating (Ca) (N)	Type	ISO/JIS Nominal Number
3.27 €	1	Available	6 Days	Stainless Steel	Open Type	4	10	3	Stainless Steel	708	Open Type	-
3.48 €	1	Available	6 Days	Stainless Steel	Open Type	8	12	2.5	Stainless Steel	506	Open Type	678
6.08 €	1		6 Days	Stainless Steel	Open Type	10	19	5	Stainless Steel	2123	Open Type	6800
4.96 €	1		6 Days	Stainless Steel	Open Type	1	3	1	Stainless Steel	80	Open Type	681
3.45 €	1	Available	6 Days	Stainless Steel	Open Type	1.5	4	1.2	Stainless Steel	125	Open Type	68/1.5
4.41 €	1		6 Days	Stainless Steel	Open Type	2	5	1.5	Stainless Steel	187	Open Type	682
3.33 €	1	Available	6 Days	Stainless Steel	Open Type	2	5	2.5	Stainless Steel	187	Open Type	-
3.17 €	1		6 Days	Stainless Steel	Open Type	2.5	6	1.8	Stainless Steel	206	Open Type	68/2.5
3.63 €	1	Available	6 Days	Stainless Steel	Open Type	3	6	2	Stainless Steel	206	Open Type	673
4.44 €	1		6 Days	Stainless Steel	Open Type	3	7	2	Stainless Steel	384	Open Type	683
3.48 €	1	Available	6 Days	Stainless Steel	Open Type	4	7	2	Stainless Steel	252	Open Type	674
5.67 €	1		6 Days	Stainless Steel	Open Type	4	9	2.5	Stainless Steel	641	Open Type	684
4.27 €	1		9 Days	Stainless Steel	Open Type	4	13	5	Stainless Steel	1306	Open Type	624
4.89 €	1		6 Days	Stainless Steel	Open Type	1.5	5	2	Stainless Steel	184	Open Type	69/1.5
3.29 €	1	Available	6 Days	Stainless Steel	Open Type	2	6	2.3	Stainless Steel	279	Open Type	692
4.14 €	1		6 Days	Stainless Steel	Open Type	3	8	3	Stainless Steel	553	Open Type	693
3.19 €	1	Available	6 Days	EN 1.3505 Equiv.	Open Type	5	10	3	EN 1.3505 Equiv.	714	Open Type	-
3.30 €	1	Available	9 Days	EN 1.3505 Equiv.	Open Type	8	16	4	EN 1.3505 Equiv.	1606	Open Type	688
3.17 €	1		6 Days	EN 1.3505 Equiv.	Open Type	3	8	3	EN 1.3505 Equiv.	553	Open Type	693

Basic information

Raceway Shape	Ball	Outer Race Type	Flat	Accuracy (JIS)	Grade 0
Specifications/Environment	Standard	Load Direction	Radial	Raceway No. of Rows	Single Row
Size Standard	Meter Size	Retainer Type	Pressed

Configure

19Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Materials of Inner and Outer Ring
- EN 1.3505 Equiv.
- Stainless Steel
Clear
I.D. D(φ)
1

1.5

2

2.5

3

4

5

6

7

8

9

10
Clear
Outer Diameter D(φ)
3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

19

22

24
Clear
Width B(mm)
1

1.2

1.5

1.8

2

2.3

2.5

2.6

3

3.5

4

5

6

7

8
Clear
Rolling Element Material
- EN 1.3505 Equiv.
- Stainless Steel
Clear
Type
- Double Shielded
- Double Shielded (snap ring fixed)
- Open Type
- With double seal
Clear
ISO/JIS Nominal Number
60/2.5ZZ

68/1.5

68/1.5ZZ

68/2.5

68/2.5ZZ

69/1.5

69/1.5ZZ

69/2.5ZZ

602ZZ

604ZZ

605ZZ

606ZZ

608ZZ

623ZZ

624

624ZZ

625ZZ

626DD

626ZZ

628ZZ

634ZZ

635ZZ

673

673ZZ

674

674ZZ

675ZZ

676ZZ

677ZZ

678

678ZZ

681

682

682ZZ

683

683ZZ

684

684ZZ

686ZZ

687ZZ

688

688DD

688ZZ

689ZZ

692

692ZZ

693

693ZZ

694ZZ

695ZZ

696ZZ

698ZZ

6800

6800ZZ

-
Clear
Type
- DDL
- DDR
- L
- R
Clear
Shield material and shape
- Open Type
- Double Shielded
- Rubber Sealed
Clear
Filter by CAD data type
- 2D
- 3D
Clear
