Fluororesin (FEP) Tube

Promotional pricing
Volume Discount

[Features]
·It has excellent chemical resistance and is ideal for fields such as chemistry, food, medical care, and semiconductors
·Excellent chemical resistance, heat resistance, weather resistance
·Successful cost reduction of 44% on average compared to SFT tubes
·Wide operating temperature range

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Save
Similar products
Product data
CAD data not available

Products homepage

Data to be displayed: 30; 45; 60

Part Number
SET1210-5-C
SET1210-20-C

Part Number	Standard Unit Price	Minimum order quantity	Volume Discount	Standard Shipping Days ?	Outer Diameter D (Ø)	O.D. [Distinction]	Inner Diameter d (Ø)	I.D. [Distinction]	Minimum Bending Radius (mm)	Length M (m)	Order Code	Mass (g)
	103.55 €	1		6 Days	12	Up to 15	10	Up to 10	67	5	442-8013	380
	242.06 €	1		24 Days	12	Up to 15	10	Up to 10	67	20	406-6014	1520

Basic information

Type	Straight	Cutting Service Usage	NA	Material	Fluororesin
Applicable Fluid	Water / Air / Chemical	Operating Environment	Standard	Color	Clear
Number of Bores(Core)	1	Material, Fluororesin	FEP	Operating Temperature Range (when using air)(°C)	-65(No Freezing)::200
Quantity	1	Operating Vacuum Level(kPa)	-100kPa	Usage Condition Details	Some conditions apply if the working fluid is water or chemical

Configure

2Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.

The part number is completed.

Basic Attributes

Outer Diameter D(Ø)
4

6

12
Clear
O.D. [Distinction]
Up to 4

Up to 6

Up to 15
Clear
Inner Diameter d(Ø)
2.5

4

9

10
Clear
Length M(m)
5

20
Clear
Order Code
406-6022

406-6014

406-5964

442-8021

442-8013

442-7971

442-7963
Clear
Type
- SET-20
- SET-5
Clear
I.D. [Distinction]
Up to 3

Up to 4

Up to 9

Up to 10
Clear
